    Six Lines Polythene T-shirt Bag Making Machine High Speed Plastic Bag Maker

    Ask Lasest Price
    Brand Name : SANBI
    Certification : CE,ISO,SGS.TUV
    Model Number : SHXJ-D600-1300
    Delivery Time : 20-30 workingdays
    Payment Terms : T/T. L/C. WESTER UNION etc.
    Supply Ability : 20SETS PER MONTH
    • Product Details
    • Company Profile

    Six Lines Polythene T-shirt Bag Making Machine High Speed Plastic Bag Maker


    High Speed Automatic Six Lines T-shirt Bag Making Machine


    Quick Detail:


    1. Computer control over the entire process.

    2. From film roll to final bag, one process flow.

    3. Servo motor, makes it easy to adjust the bag length and the production speed.

    4. Automatic film feeding, coordination free from tension adjustment.

    5. Automatically stop when film feeding blocks or bags jam.

    6. High production efficiency to save manpower and time.

    7. Equipment with heat sealing and cold cutting device

    8. Arrange two layer, each layer with three lines more capacity

    Place of Origin:

    China

    Brand Name:

    SANBI

    Certification:

    CE, ISO ,SGS


    Description:


    This is High Speed Automatic heat sealing cold cutting ,Double-layer, Six-line, Bottom Sealing Bag-making Machine , applied to manufacturing and printing the uncolored flat-opening and vest bags made of HDPE, LDPE roll film. It is automatically controlled by the computer completely. The user can optional it by the touch panel (PLC)

    The main motor adopts variable frequency motor which is more power-efficient and more freely for speed-regulate. has such functions as photoelectric automatic tracking microcomputer length setting, high limit stopping, automatic counting, automatic alarm on reaching the set value, high compensation accuracy with such characteristics as neatbags, little error and high automatic of whole machine, so it is a kind of ideal equipment for producing blank bags, colour bags, flat bags and vest bags, etc. And other various plastic soft packing bags.


    Applications:


    - HDPE .LDPE T-shirt bag ,Shopping bag ,garbage bag .

    - food packaging:cakes,candies,roasted seeds and nuts,

    - biscuits, milk powder, salt,tea, bag etc.;

    - bacteria bags,convenient bags,storage bags;

    - Woven inner bag


    Specifications :


    Model

    SHXJ-D 900

    SHXJ-D 1000

    SHXJ-D 1100

    SHXJ-D 1200

    SHXJ-D 1300

    Width of sealing and cutting (mm)

    880mm

    980

    1080

    1180

    1280

    Max. of bag width (mm)

    Max. of bag length

    230mm*3 *2

    1000mm

    260mm*3mm*2

    1000mm

    300mm*3mm*2

    1000mm

    330*3*2

    1000mm

    360*3* 2

    1000mm

    Bag-making speed

    Product thickness

    40-100pcs/rain * 6

    0.01-0.2mm

    40-100pcs/rain * 6

    0.01-0.2mm

    40-100pcs/rain * 6

    0.01-0.2mm

    40-100pcs/rain x 6

    0.01-0.2mm

    40-100pcs/rain *6

    0.01-0.2mm

    Main motor

    Feeding motor

    1.5kw 300*6w

    2.2kw 300*6w

    2.2kw 300*6w

    3kw 300*6w

    4kw 300*6w

    Heater power Power suppty

    850*4w

    50HZ 220V+10%-15%

    1200*4w

    50HZ 220V+10%-15%

    1200*4w

    50HZ 220V+10%-15%

    1500*4w

    50HZ 220V+10%-15%

    1800*4w

    50HZ 220V+10%-15%

    OVERALL DIMENSIONS (L×W×H) WEIGHT OF OVERALL

    3500×1600×

    1700mm 1300kg

    3500×1800

    ×1700mm 1400kg

    3500×1800

    ×1700mm 1400kg

    3500×1900

    ×1700mm 1500kg

    3500×2200×2000mm 1600kg


    Competitive Advantage:


    a. The twenty-seven years experence to manufacture this machine

    b. 30years professional engineers service in many countries,

    c. Machines with quality guarantee for one year, life-long maintenance.

    d. Created honors : The national igh tech-Enterprises, The national torch-planning project commitments to corporate. Famouse trademarks in WENZHOU, Ten pcs provincial new products etc

    e. Professional development group continuously improves and upgrades new products and new technologies .

    f. Undertake various non-standard machinery, solve the customers' special requirements.
