1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die

    Buy cheap 1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die from wholesalers

    Buy cheap 1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die from wholesalers
    • Buy cheap 1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die from wholesalers

    1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die

    Ask Lasest Price
    Brand Name : Sanbi
    Certification : CE, ISO9001
    Model Number : SJ-B55
    Price : 13000
    Delivery Time : within 30 workdays
    Payment Terms : T/T, L/C
    Supply Ability : 30sest/month
    • Product Details
    • Company Profile

    1000mm width LDPE / HDPE Film Blowing Machine With Rotary Die

    1000mm width LDPE / HD PE Film Blowing Machine With Rotary Die Used for foodstuff, clothing, rubbish bag ad vest bags


    Quick Detail:


    1.Top quality film blowing machine

    2.High quality products

    3.Quality first, customer first

    Plastic Film Blowing Machine


    Condition

    New

    Application

    Film

    Plastic Processed

    PE

    Blow Moulding Type

    Extrusion Blow Moulding

    Automatic

    Yes

    Place of Origin

    Zhejiang, China (Mainland)

    Brand Name

    SANBI

    Model Number

    SJ-B50/55/65/70

    Voltage

    380V / as request

    Power(W)

    22/26/40/45KW

    Dimension(L*W*H)

    7300*2900*5800mm

    Weight

    2.5/2.9/3.4/3.5T

    Certification

    ISO 9000 ,CE

    Warranty

    1 Year

    After-sales Service Provided

    Engineers available to service machinery overseas

    Certificate

    CE,ISO 9000

    Material

    HDPE,LDPE ,LLDPE

    Product Type

    Pe Film

    Processing Type

    Extruding Machine

    quality

    top quality

    service

    high quality service

    Plastic Film Blowing Machine

    Plastic Film Blowing Machine

    type

    Film Blowing Machine

    supplier

    trustworthy

    The product

    Popular worldwide


    Description:


    It is used for blowing high-low pressure polyethylene, which has been widely used for producing laminating film, packing film, agricultural covering film, bag or film for textile and clothing and other packing material. The main motor adopts variable frequency motor to improve the speed regulating stability and save electricity by 30%. The screw and material barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, it can achieve the best effect of cooling.

    Applications:

    Its extruder, cylinder and screw are made of quality alloy steelwhich have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like LDPE, HDPE and LLDPE, widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest bags.


    Specifications:


    Model

    SJ-B50

    SJ-B55

    SJ-B65

    SJ-B65-1

    Diameter of Screw(mm)

    Φ50

    Φ55

    Φ60

    Φ65

    L/D ratio of screw

    28:1

    28:1

    28:1

    28:1

    Speed of screw(r/min)

    10-100

    10-100

    10-100

    10-100

    Power of Main Motor(kw)

    11

    15

    22

    22

    Max. Output(kg/h)

    35

    50

    65

    80

    Max. Lay-flat Width of Film(mm)

    600

    800

    1000

    1200

    Thickness of Film (mm)

    0.01-0.10

    0.01-0.10

    0.01-0.10

    0.01-0.10

    Total Power(kw)

    22

    26

    30

    36

    Weight of Machine(T)

    2

    2.3

    2.6

    3

    Overall Dimensions

    (L*W*H)(m)

    4*1.8*4.6

    4.2*2*4.9

    4.6*2.3*5.6

    4.8*2.5*5.8


    Optional equipment


    Name

    auto loader

    cast Aluminum Heating ring

    pneumatic device

    air shaft

    Aluminum Shape ring


    Spare parts


    01

    filter

    3M

    12

    electric –testing pen

    1 pc

    02

    magnetic stone

    1 pc

    13

    screw blade

    1 pc

    03

    air pipe

    1 pc

    14

    hexageonic wrench

    1 pc

    04

    electric-thermal couple

    2 pcs

    15

    glove

    4 pairs

    05

    screw heater(stainless steel)

    1 pc

    16

    digital temperature meter

    1 pc

    06

    three-through heater

    1 pc

    17

    current meter

    1 pc

    07

    Breaker DZ47 1P 32A

    1 pc

    18

    A.C contactor CJX1-22A/220V

    1 pc

    08

    Butter Y090

    1 pc

    19

    point X5-2010

    2 pcs

    09

    8-10 open and wrench

    1 pc

    20

    main switch

    1 pc

    10

    14-17 open and wrench

    1 pc

    21

    8# monkey wrench

    1 pc

    11

    17-19 open and wrench

    1 pc

    22

    8# needle nose pliers

    1 pc
