    22-50KW Single Winder Polyethylene blown film extruder with gusset device

    Ask Lasest Price
    Brand Name : SANBI
    Certification : CE, ISO9001
    Model Number : SJ-A50
    Price : 8000
    Delivery Time : within 30 workdays
    Payment Terms : T/T, L/C
    Supply Ability : 30sest/month
    • Product Details
    • Company Profile

    22-50KW Single Winder Polyethylene blown film extruder with gusset device

    Single Winder with gusset device LDPE/HD PE Film Blowing Machine used for packing all kinds of plastic bags


    Quick Detail:


    1.certificate: CE
    2. high quality with the most competitive price
    3.make special accoring to the client requirment


    Condition

    New

    Application

    Film

    Plastic Processed

    PE

    Blow Moulding Type

    Extrusion Blow Moulding

    Automatic

    Yes

    Place of Origin

    Zhejiang, China (Mainland)

    Brand Name

    SANBI

    Model Number

    SJ-A50/55/65/70

    Voltage

    380V / as request

    Power(W)

    22-50KW

    Dimension(L*W*H)

    6500*2500*5150mm

    Weight

    1.8/2.2/2.6/2.8T

    Certification

    ISO 9000 ,CE

    Warranty

    1 Year

    After-sales Service Provided

    Engineers available to service machinery overseas

    Certificate

    CE,ISO 9000

    Material

    HDPE,LDPE ,LLDPE

    Product Type

    Pe Film

    Processing Type

    Extruding Machine

    quality

    top quality

    service

    high quality service

    Plastic Film Blowing Machine

    Plastic Film Blowing Machine

    type

    Film Blowing Machine

    supplier

    trustworthy

    The product

    Popular worldwide


    Description:


    Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE).

    Optional Equipment:


    1)AUTO LOAD
    2)CAST ALUM HEATER
    3)AIR SHAFT
    4)DIE ROTARY DEVICE
    5)BOUBLE SIDES WINDER

    6)UP AND DOWN

    Applications:


    It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
    Specifications:


    Model

    SJ-A50

    SJ-A55

    SJ-A65

    SJ-A65-1

    Diameter of screw

    φ50

    φ55

    φ65

    φ65

    Lay-flat width of film(mm)

    100-600

    200-800

    300-1000

    400-1200

    Thickness of film(mm)

    0.01-0.10

    0.01-0.10

    0.01-0.10

    0.01-0.10

    Max. output(kg/h)

    35

    50

    65

    80

    L/D ratio of screw

    28:1

    28:1

    28:1

    28:1

    Power of main motor(kw)

    11

    15

    22

    22

    Power of Traction motor(kw)

    1.1

    1.1

    1.5

    1.5

    Heating Power(kw)

    11

    13

    19

    21

    Overall dimension(L*W*H) (m)

    4.8*1.9*3.8

    5.5*2.1*4.6

    6.5*2.3*5.2

    6.500*2.5*5.2

    Weight(T)

    1.5

    2

    2.3

    2.6



    PE Film Blowing Machine
